103
Menu map
For menu operation, connect a TV to this unit and display the menu on the TV screen. For menu operations, see the following page.
By default, this unit has recommended settings defined. You can customize this unit based on your existing system and your preferences.
How to make detailed settings
Setting items Detailed items Description Page
Audio
Dialog Level Sets the output level to clarify the dialogue
output from the center channel.
109
Subwoofer Level This setting adjusts the volume level for the
subwoofer.
109
Surround Parameter Adjusts surround sound parameters.
109
Tone Adjusts the tonal quality of the sound.
111
M-DAX Expands the low and high frequency components
of compressed audio content such as MP3 files
to enable richer audio playback.
111
Audio Delay Compensates for incorrect timing between video
and audio.
112
Volume Set the MAIN ZONE (room where the unit is
located) volume setting.
112
Audyssey Makes Audyssey MultEQ
®
, Audyssey Dynamic
EQ
®
and Audyssey Dynamic Volume
®
settings.
112
Graphic EQ Uses the graphic equalizer to adjust the tone of
each speaker.
113
Video
Picture Adjust Adjusts the video quality.
115
HDMI Setup Makes settings for HDMI video/audio output.
115
Output Settings Makes screen-related settings.
116
On Screen Display Select the on-screen display user interface
preferences.
118
TV Format Set the video output signal format for the TV you
are using.
118
Setting items Detailed items Description Page
Inputs
Input Assign Changes input connector assignment.
120
Source Rename Changes the display name for this source.
122
Hide Sources Remove from the display input sources that are
not used.
122
Source Level Adjusts the playback level of the audio input.
122
Input Select Sets the audio input mode and decode mode.
122
Speakers
Audyssey
®
Setup The acoustic characteristics of the connected
speakers and listening room are measured and
the optimum settings are made automatically.
22,91
Manual Setup Perform when setting the speakers manually
or when changing settings made in Audyssey
®
Setup.
124
Network
Information Display network information.
128
IP Control Enables network communication in standby
power mode.
128
Friendly Name The Friendly Name is the name of this unit
displayed on the network. You can change the
Friendly Name according to your preferences.
128
Settings Make settings for wired LAN.
129
Diagnostics Used to check the network connection.
130
Maintenance Mode Use when receiving maintenance from a Marantz
service engineer or custom installer.
130
