NTI RACKMUX RACKMOUNT ANSI TERMINAL DRAWER
36
Supported VT100, VT220 and Console ANSI Commands, Cont'd
Command
FUNCTION VT100, VT220 Console ANSI
Request keyboard status report CSI ? 26 n Same
Respond with keyboard language CSI ? 27; Ps n Same
(see table below for values of “Ps”)
Values of Ps (above)
Ps
Keyboard Language
Ps
Keyboard Language
1 U.S. 6 Spanish
2 U.K. 7 Swedish
3 Danish 8 Norwegian
4 German 9 Italian
5 French
*1. More than one mode, but less than 17, may be set with one sequence. Enter multiple numeric parameters separated
by semicolons (;). However you cannot combine sequences containing "?" with those that don't contain "?", nor can
you combine sequences ending with "h" with those ending with "l".
*2. To toggle monitor mode from the keyboard, press CTRL SHIFT 1 (use the 1 on the numeric keypad).
*3. In VT52 or VT100 modes, displays checkerboard character.
6.2 VT52 Command Guide
Table 11- VT52 Mode Escape Sequences
Command VT52
Move cursor up one line ESC A
Move cursor down one line ESC B
Move cursor right one column ESC C
Move cursor left one column ESC D
Move cursor to home position ESC H
Move cursor up one line with scroll ESC I
Move cursor to line line, column col ESC Y line col
Select graphics character set ESC F
Select U.S. ASCII character set ESC G
Erase from cursor to end of display ESC J
Erase from cursor to end of line ESC K
Print cursor line ESC V
Print display ESC ]
Transparent print mode on ESC W
Transparent print mode off ESC X
Copy print mode on ESC ^
Copy print mode off ESC _
Keypad application mode on ESC =
Keypad application mode off ESC >
Enter VT100 mode ESC <
Identify terminal ESC Z
