Exit push to talk
Select Options > Exit. Select Yes to log out and close the
service. Press No if you want to keep the application
active on the background.
Net calls
With the net call service (network service), you can
make and receive calls over the Internet.
Your device supports voice calls over the Internet
(Internet calls). Your device attempts emergency calls
primarily over cellular networks. If an emergency call
using cellular networks is not successful, then your
device attempts an emergency call through your
Internet call provider. Due to the established nature of
cellular telephony, you should use cellular networks for
emergency calls, if possible. If you have cellular network
coverage available, please make sure that your cellular
phone is switched on and ready to make calls before
you attempt an emergency call. The capability for an
emergency call using Internet telephony depends on
the availability of a WLAN network and your Internet
call provider's implementation of emergency call
capabilities. Contact your Internet call provider to check
the Internet telephony emergency call capability.
VoIP (voice over Internet protocol) technology is a set
of protocols that facilitate phone calls over an IP
network, such as the Internet. VoIP phone calls can be
established between computers, between mobile
phones, and between a VoIP device and a traditional
telephone. To make or receive a VoIP call, your device
must be within WLAN coverage, for example.
The availability of the net call service may vary
according to your country or sales area.
Define the net call settings
Before you can make net calls, you need to define the
net call settings. After you have defined the net call
settings with these instructions, your device logs in to
the net call service automatically, when you select
Menu > Connect. > Internet tel..
First: define a SIP profile
1. Select Menu > Tools > Settings > Connection > SIP
settings > Options > Add new, and enter the
required information. You must define all available
SIP settings, but ensure that Registration is set to
Always on. Contact your net call provider for the
correct information.
2. Select Proxy server, and set Transport type to Auto.
3. Select Back until you return to the Connection menu.
Second: define a net call profile
1. Select Internet tel. settings > Options > New
profile. Enter a name for the profile, and select the
SIP profile you just created.
2. Select Back until you return to the main menu.
Third: select a preferred net call profile (optional)
If you select a preferred net call profile, Internet tel.
automatically uses this network profile to connect to
the net call service.
1. Select Menu > Connect. > Internet tel..
2. Select Preferred profile, and the net call profile you
just created.
50
Make calls
