Integrated camera with a smart design offering high resolution and
smooth movement.
High resolution, high definition shooting
Compatible with four (HD/SD) video formats
On-screen menu-functions let you
easily switch between 1080i,720p,
576i and 576psF formats. What's
more, simultaneous HD and SD
output enables smooth transition
from SD to HD production.
Highly sensitive progressive 3CCD, excellent for shooting indoors
Delivers highly sensitivity,
high S/N, and high resolution by
employing the wide light collecting
surface of 1/3-inch CCD.
High definition, 13x zoom lens with auto and remote focus
An 13x, HD zoom lens with a fast
F1.6 maximum aperture provides
both manual/remote and accurate
autofocus capabilities.
Equipped with the same
Panasonic exclusive high-
precision Digital Signal
Processing (DSP) found in our
high-end broadcast cameras,
the AW-HE100 delivers rich,
vibrant video quality
(i.e.gamma correction).
Wide-area pan-tilt and Smart Flip function provide versatile coverage
The AW-HE100 provides a wide range
of motion, with a pan range of
+
-
175 ° and
a tilt range from +210 ° to -40 °.
The camera also includes a versatile,
use selectable Smart Flip function to
automatically reverse the vertical
orientation of the picture to provide
natural looking video, even when the
subject passes directly under the camera.
High speed, accurate movement unfalteringly captures the dynamism of sports
Has both high speed motion of
60 °/s and pan-tilt stop accuracy
of
+
-
3' (0.05 °).
The camera accurately can track
high speed sports such as
swimming and skating.
Shoot without disrupting the ambience with the silence of NC30
Operation is extremely quiet,
with a noise level of just NC 30
(during 30 °/s operation),
which is about as quiet as a
library. This lets you achieve
natural shooting results at
weddings and in theaters and
other locations where mood and
atmosphere play an important
role.
Rich preset memory offering up to 100 positions
Various camera and lens position
may be preset and memorized for
easy recall. This is useful in
situations where many fixed shots
are required, and where non-
technical personnel may need to
operate the cameras.
• The number of preset memory positions
will differ depending on the controller.
Stylish body compatible with installation on surfaces and ceiling
Integrated smart design (pan-tilt,
zoom lens, and camera), for
simple cabling and installation on
ceilings or walls.
Compatible formats
H D
1080/50i, 720/50p
S D
576/50i, 576/25psF
Reproduces a bright and crisp image even indoors.
Integrated zoom lens developed for HD Delivers beautiful, low noise images
Shoot from precise angles with broad range of
movement
Shoot while preserving the natural ambience
Easily shoots the intense motion of sports
Easily switch between many positions
Broad range/high speed/precise rotation movement
Easy installation/comfortable operation
Wireless remote control supplied as standard
Range approximately 10 m (with no obstructions). However, the distance may become shorter if direct sunlight,
light from a fluorescent lamp or light from a plasma display falls on the AW-HE100 main unit's IR receptor.
A full-featured wireless remote for
control of up to four cameras is included
as a standard accessory. The AW-HE100
is also compatible with current
Panasonic RS-422 wired remote control
systems for easy operation and
adjustment.
14-bit A/D Converter & 19-bit Digital Signal Processing (DSP)
4
