P/N: 4809644
©2005 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
13DEC04 v2.0 03-05Viper(4809644v2.0)
vii
8PN301-040 POWER COOLER ASSY. ' VIPER 1
8PN201-040 DISCHARGE ASSY. '03 VIPER 1
8PN101-040 CAC ASSY, '03 VIPER, AIR/WATER 1
4PCW012-030 DUCT, DISCHARGE, '03 VIPER 1
7J006-093 6mm WASHER, PLATED 4
7P125-025 1/8"NPT x 5/32" HOSE 90 1
7P375-250 3/8" x 3/8" x 1/4" MALE BARB TEE 1
7P500-034 1/2"NPT 3/4" BARB 90° 2
7PS300-200 SLEEVE, BLACK, Ø3.00" x 2.00"L 1
7PS375-200 SLEEVE, BLACK, Ø3.75" x 2.00"L 1
7PS450-200 SLEEVE, BLACK, Ø4.5" x 2.0"L 1
7R002-048 #48 GOLDSEAL HOSE CLAMP 2
7R002-060 #60 GOLDSEAL HOSE CLAMP 2
7R002-072 #72 GOLDSEAL HOSE CLAMP 2
7U030-046 5/32" VACUUM LINE 8'
7U100-065 GROMMET, 5"ID, .812"OD, .187" GRV 1
7U133-060 3/4" x 90° HOSE, LONG 1
8D204-010 RACE BYPASS VALVE, BLACK 1
8H040-175 FILTER, 1-3/4"ID, MFRB 1
8N055-050 PLASTIC CAP, SURGE TANK 1
8PN105-040 WATER TANK MTG ASSY, VIPER 1
8PN010-170 SUPPORT,WATER TANK, '03 VIPER 1
7A250-051 1/4-20 x .50" HXHD ZN PLT 2
7A250-075 1/4-20 x .75" SHCD PLTD 1
7F250-021 1/4-20 NYLOCK NUT 1
7J250-001 1/4" SAE WASHER, PLTD 4
7P375-075 3/4" HOSE UNION 2
7P500-026 1/2"NPT, 3/4" BARB, 90° 6
7R007-001 NYLON CLAMP, 1-1/8" 12
7U038-000 3/4" HEATER HOSE 6'
7U038-012 HOSE, Ø3/4" 90°, 4 x 12" 3
8N055-030 TANK, LT1 AFTERCOOLER 1
8PN106-040 WATERCOOLER ASSY, VIPER 1
7A250-074 1/4-20 x 3/4" HXHD PLT 6
7F250-021 1/4-20 NYLOCK NUT ZINC PLTD 6
7J250-001 1/4" SAE WASHER, PLTD 12
8N006-010 WATERCOOLER 1
8PN010-150 SUPPORT, DS VIPER, SRT10 1
8PN010-160 SUPPORT, PS VIPER, SRT10 1
8PN107-020 WATER PUMP ASSY, VIPER 1
5W001-005 3/8" PLASTIC WIRE LOOM 7'
5W001-009 16-14GA MALE SLIDE INSULATED 1
5W001-010 16-14GA FEMALE SLIDE INSULATED 3
5W001-011 16-14GA EYELET .25" HOLE 2
5W001-013 14-16AWG, SOLDERLESS CONNECTOR 2
5W001-014 FUSE HOLDER, 10GA WIRE 1
5W001-015 FUSE, BLADE TYPE 20AMP 1
5W001-016 RELAY, BOSCH 1
5W001-017 3/8" RING TERMINAL 12GA 1
5W001-040 12-10GA FEMALE SLIDE INSULATED 1
5W014-010 14GA STRD WIRE RED, UL1015 7'
5W014-030 14GA STRD WIRE, BLACK 2'
5W014-030 14GA STRD WIRE, BLACK 7'
5W016-010 WIRE, STRND, 16AWG, YELLOW 2'
7GL10-150 10mm x 1.5" NYLOCK NUT 1
7U100-044 TIE-WRAP, 4" NYLON 8
8F001-402 PUMP, WATER PIERBURG 1
2003-2005 Dodge Viper
Part No. 1201840
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any short-
ages or damaged parts immediately.
PART NO. DESCRIPTION QTY PART NO. DESCRIPTION QTY
PA RTS LIST
