P/N: 4809655
©2007 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
16AUG07 v1.0 96-03MusGT(4809655v1.0)
A-4
-----
-----
1300 BEACON PLACE OXNARD, CA 93033
TEL: (805) 604-1336 FAX: (805) 604-1337
CAD GENERATED DRAWING,
DO NOT MANUALLY UPDATE
SCALE:
SIZE: DWG. NO.:
D
SHEET 1 OF 1
REV.
DATE
APPROVALS
DRAWN
ENGINEERING
R&D
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
DECIMALS:
.XX± .01
.XXX±.005
MATERIAL
FINISH
NONE
SEE PARTS LIST
DO NOT SCALE DRAWING
WEIGHT
8.0 LBS
3:4
1016606
F
FRACTIONS:
ANGLES: ±1/16
±1/2•
ASY, S/C MTG BRKT
APPR.
-----
4/15/09
1996-1998 4.6L MUSTANG
JF
-----
-----
-----
REPLACE STOCK
FLANGE-HEAD BOLT
ON WATER PUMP
NOTES: UNLESS OTHERWISE SPECIFIED
1. PARTS TO BE SHIPPED LOOSE.
2. IMPORTANT: CUT ITEM 17 SO THAT IT DOES NOT PROTRUDE PAST MACHINED SURFACE OF ITEM 3.
DO NOT USE A 1-1/2" BOLT.
3. IF VEHICLE IS EQUIPED WITH COIL PACK, USE ITEM 8. IF VEHICLE IS NOT EQUIPPED
WITH COIL PACK, USE ITEM 5.
4. FOR USE IN 96 - 97 MODEL YEARS ONLY.
TO SMOG PUMP
TO STOCK
ALTERNATOR
TO MTG LOCATION
ON WATER PUMP
TO ENGINE BLOCK
EXISTING
STOCK
SCREW
MODIFIED THERMACTOR VALVE
TO EXHAUST
MANIFOLD
TO VACUUM
SOURCE
1
MOUNT COIL PACK w/ STOCK HARDWARE.
(IF VEHICLE IS NOT EQUIPPED WITH
COIL PACK, THIS ITEM IS NOT USED)
36
35
36
TO ENGINE
23 16
TO ENGINE
19
13
17 16
SEE NOTE 2
11
12
28
29
10
15
13
6
30
13
3
REPLACE STOCK STUD
ON TIMING COVER
UPPER PASSENGER
(R.H.) SIDE
27
24
4
5
8
OR
5
SEE NOTE 3
2
2216
2113
TO ENGINE
2013 TO ENGINE
314
33324
25 16
TO S/C
7
9
2516
1413
18
13
2616
1
1
4
4
4
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
32
34
34
35
36
35
36
37
1
1
1
1
1
1
1
1
2
1
1
1
8
1
1
10
1
2
1
1
1
2
1
1
5
1
1
1
1
1
1
1
1
1
2
1
1
2
4PFH010-034
4PFH010-041
4PFK010-021
4PFH010-044
2A017-753-02
2A017-875-03
2A017-750-01
2A017-875-01
2A017-876-02
4PFK017-011
4FR016-150
2H040-011
7J312-000
7C080-066
7C080-056
7J375-044
7A375-165
7C080-030
7C080-081
7C080-090
7C080-160
7A375-276
7A375-425
2A017-876-01
7A375-124
7A375-100
7C010-060
7C010-065
7K312-001
7C080-070
4PFK010-010
2A046-113
7J250-001
7U040-000
7R002-006
7A250-051
7U040-000
7R002-006
PLATE, FRONT S/C MTG BRKT
BRKT, MTG COIL
PLATE, MTG IDLER
PLATE, REAR S/C MTG BRKT
SPACER, .875"OD x 3.123"L x .404"ID
SPACER, .750"OD x 1.690"L x .328"ID
SPACER, .875"OD x 1.315"L x .404"ID
SPACER, .875" x 1.25"L
COLLAR, STEP IDLER (SMOOTH)
PULLEY IDLER SMOOTH 3"
PULLEY RETAINER S/C
WASHER, 5/16" FLAT SAE GR5
SCREW, M8-1.25 x 66mm HXHD CL 10.9
SCREW, M8-1.25 x 55mm HXHD CL 10.9
WASHER, 3/8"SAE PLTD
SCREW, 3/8-16 x 1.65" HXHD MOD. GR8
SCREW, M8-1.25 x 30mm HXHD CL 10.9
SCREW, M8-1.25 x 80mm HXHD CL 10.9
SCREW, M8-1.25 x 90mm HXHD CL 10.9
SCREW, M8-1.25 x 160mm HXHD CL 10.9
SCREW, 3/8-16 x 2.75" HXHD GR5
SCREW, 3/8-16 x 4.25" HXHD GR5
SPACER, .875"OD x .952"L x .328"ID
3/8-16 x 1-1/4" HXHD
3/8-16 x 1" HXHD
SCREW, M8-1.25 x 60mm HXHD CL10.9
SCREW, M8-1.25 x 65mm HXHD CL 10.9
WASHER, 5/16" AN, PLATED
SCREW, M8-1.25 x 70mm HXHD CL 10.9
BRKT, MTG THERMACTOR VALVE
BELT, 6-GRV GATORBACK, 113"L x 21mm THK
WASHER, 1/4"SAE, PLATED
HOSE, 1/2" SILCONE
CLAMP, HOSE, #6
SCREW, 1/4-20 x .50" HXHD, PLATED
1/2" SILICONE HOSE, HIGH TEMP
#6 SS HOSE CLAMP
ITEM NO. QTY PART NO. DESCRIPTION
C 1016606 ASY, S/C MTG BRKT
