Philips indoor luminaires8.40 Light-line systems
TTX400
TTX400aluminumreectors
These aluminum one-piece reectors for both TL5 and TL-D lamps
are available in hammered, matt and glossy versions. The TL5 ones are
smaller due to the smaller lamps, resulting in easier handling and less
space needed. TTX400 aluminum reectors are specially designed for
applications where a wide beam, narrow beam, very narrow beam
or ultra- narrow beam is required e.g. distribution centeres and
warehouses. Installation is via a simple click-in action to the electrical
units TMX400. The high efciencies of these reectors ensure a highly
cost effective solution. Reector overlapping and mechanical clips
delivered with the reectors enable proper alignment in the event of
continuous lines. All aluminum reectors are available for 49 W and
54 W lengths.
TTX400 TL5
Aluminum reectors
Type GMX565, GMX566, GMX567, GMX570
Suitable electrical unit For 1 and 2 TL5 35/49/80 W and 54/28 W
versions
Material and light
distribution
GMX565:
matt aluminum, narrow beam (M-NB)
high-gloss hammer-bow aluminum, narrow beam
(HB-NB)
GMX566:
matt aluminum, wide beam (M-WB)
high-gloss hammer-bow aluminum, wide beam
(HB-WB)
high-gloss hammer-bow aluminum, asymmetric
beam (HB-A)
GMX567:
matt aluminum, asymmetric beam (M-A)
GMX570:
high-gloss aluminum, ultra narrow beam (C-NB)
high-gloss hammer-bow aluminum, ultra narrow
beam (HB-NB)
Installation One click-in action to electrical unit
Remarks All reectors are in one piece
Reectors are suitable for 1- and 2 lamp versions,
GMX566 M-WB and HB-A for 49 W version only
Main applications Retail (e.g. food, fashion), industry, warehouses
Where relevant, for detailed descriptions of Lighting Controls we refer you to chapter 11, and descriptions for e.g. optics/optical covers, lamps data, photometrical diagrams, etc. to the respective sections in chapter 12.
TTX400 TL-D
Aluminum reectors
Type GMX440, GMX460, GMX465, GMX466, GMX467,
GMX470
Suitable electrical unit For 1 and/or 2 TL-D 36 and 58 W versions
Material and light
distribution
GMX440:
matt aluminum, for general lighting, both 1- and
2-lamp 36 and 58 W version*
GMX460:
high-gloss aluminum, narrow beam (C-NB),
1-lamp 58 W version*
GMX465:
high-gloss hammer-bow aluminum, narrow beam
(HB-NB), 1- and 2-lamp 58 W version*
matt aluminum, narrow beam (M-NB), 1- and
2-lamp 58 W version*
GMX466:
high-gloss hammer-bow aluminum, asymmetrical
(wall washer) beam (HB-A), 1-lamp 58 W
version*
high-gloss hammer-bow aluminum, wide beam
(HB-WB), 2-lamp 58 W version
matt aluminum, wide beam (M-WB), 2-lamp
58 W version
GMX467:
matt aluminum, asymmetrical beam (M-A),
1-lamp 36 and 58 W version*
GMX470:
high-gloss aluminum, very narrow beam (C-NB),
1-lamp 58 W version*
* Also for TMX400 electrical unit, 2-lamp version
with F32 lampholder
Installation One click-in action to electrical unit
Remarks All reectors are of one piece
Main applications Retail (e.g. food, fashion), industry, warehouses
