Bass boost:
Gain ......................................+12 dB to 0 dB
CD player
System ..........................................Compact discaudio system
Usable discs ..............................Compact disc
Signal-to-noise ratio ...............94 dB (1 kHz) (IHF-A net-
work)
Number ofchannels ..............2 (stereo)
MP3 decoding format ...........MPEG-1 &2 AudioLayer 3
WMA decodingformat .........Ver. 7, 7.1, 8,9, 10,11 (2ch
audio)
(WindowsMediaPlayer)
AAC decodingformat............MPEG-4 AAC (iTunes en-
coded only)(.m4a)
(Ver.8.2 and earlier)
WAVsignal format..................Linear PCM & MS ADPCM
USB
USB standardspecification
.....................................................USB 2.0 full speed
Maximum currentsupply ....500 mA
USB Class ...................................MSC (Mass Storage Class)
Filesystem ..................................FAT12,FAT16,FAT32
MP3 decoding format ...........MPEG-1 &2 AudioLayer 3
WMA decodingformat .........Ver. 7, 7.1, 8,9, 10,11 (2ch
audio)
(WindowsMediaPlayer)
AAC decodingformat............MPEG-4 AAC (iTunes en-
coded only)(.m4a)
(Ver.8.2 and earlier)
WAVsignal format..................Linear PCM & MS ADPCM
(Non-compressed)
FM tuner
Frequency range ......................87.9 MHzto 107.9MHz
Usable sensitivity.....................9 dBf (0.8 µV/75W,mono,
S/N:30 dB)
Signal-to-noise ratio ...............80 dB (digital broadcasting)
(IHF-A network)
Signal-to-noise ratio ...............72 dB (analog broadcasting)
(IHF-A network)
AM tuner
Frequency range ......................530 kHz to 1710 kHz
Usable sensitivity.....................28 µV (S/N: 20 dB)
Signal-to-noise ratio ...............80 dB (digital broadcasting)
(IHF-A network)
Signal-to-noise ratio ...............62 dB (analog broadcasting)
(IHF-A network)
CEA2006 Specifications
Power output .............................14 W RMS × 4 Channels (4
Wand ≦1 %THD+N)
S/N ratio.......................................91 dBA (reference:1 Winto
4W)
Note
Specifications and the design are subject tomod-
ifications without notice.
Additional Information
En
28
Appendix
