FGSW-2620VM / FGSW-2624SF User’s Manual
Object Description
802.1x Protocol
Disable or enable 802.1x Protocol.
Radius Server IP
Set the Radius Server IP address.
Server Port
Set the UDP destination port for authentication requests to the specified Radius
Server.
Accounting Port
Set the UDP destination port for accounting requests to the specified Radius
Server.
Shared Key
Set an encryption key for use during authentication sessions with the specified
radius server. This key must match the encryption key used on the Radius Server.
NAS, Identifier
Set the identifier for the radius client.
Apply Button
Press this button to save the value on the Switch.
3. Setup the RADIUS server and assign the client IP address to the Web-Smart switch. In this case, field in the
default IP Address of the Web-Smart switch with 192.168.0.100. And also make sure the shared secret key is as
same as the one you had set at the switch RADIUS server – 12345678 at this case.
4. Configure ports attribute of 802.1X, see the next section “Per Port Status Configuration”.
67
