Appendix A
Specifications
Model WAP-4060PE
Standard IEEE 802.11b, 802.11g
Signal Type DSSS (Direct Sequence Spread Spectrum)
Modulation
OFDM with BPSK, QPSK, 16QAM, 64QAM, DBPSK, DQPSK,
CCK
Port 10/100Mbps RJ-45 port * 1, 802.3af compliant
Antenna Connector
Reverse SMA male * 1
Output Power 18dBm
802.11b
11 Mbps (CCK): -85dBm
5.5 Mbps (QPSK): - 89dBm
1, 2 Mbps (BPSK): - 90dBm
(typically @PER < 8% packet size 1024 and
@25ºC + 5ºC)
Sensitivity
802.11g
54 Mbps: -72dBm
48 Mbps: - 72dBm
36 Mbps: -76dBm
24 Mbps: -79dBm
18 Mbps: -82dBm
12 Mbps: -86dBm
9 Mbps: -89dBm
6 Mbps: -90dBm
(typically @PER < 8% packet size 1024 and
@25ºC + 5ºC)
Operating Mode AP, AP Client, Wireless Bridge, Multiple Bridge, Repeater
Security
Open, shared, WPA, and WPA-PSK authentication
802.1x support
EAP-TLS, EAP-TTLS, PEAP
Block inter-wireless station communication
Block SSID broadcast
