Assembly Section 3-14
FL20M/FL14M 10/03
ASSEMBLY
ASSEMBLY
© 2004 Alamo Group Inc.
FIGURE 24 FIGURE 25
FIGURE 26
CANOPY SHIELDS
After final adjustment attach Canopy Shields over Divider Gearbox (FIGURE 26) , Secondary Gearbox (FIGURE
24 & 25).
CAUTION Install all Canopy Shields over Torque Limiters and Drivelines and make certain they
remain installed at all times when operating this Cutter.
R 09-27-01
