Other Features
42
4
communication failure report is
printed after a job has been com-
pleted. And at the end, it prints a
communication failure or trans-
mission result report. Check it, and
retransmit any pages that were not
sent. If a particular problem con-
tinues or gets worse, keep the error
reports for the service technician.
❖
❖❖
❖
Polling Result Report
This report is printed after your
machine polls a message from an-
other machine.
❖
❖❖
❖
Printing Part of the Image on the Re-
port (Switch 04, bit 7)
For reference purposes, the ma-
chine prints the first few inches of
the fax message on the following
reports.
• Communication Result
• File Reserve
• Communication Failure Report
Report formats
❖
❖❖
❖
The Mode Column
See the bottom of the Journal for a full listing of symbols on the Journal. On
other reports a code is given, informing the type of communication. These
codes are explained below.
❖
❖❖
❖
The Result Column
OK: Successful communication
E: An error occurred
* * * COMMUNICATION RESULT REPORT (NOV.24.1998 9:19PM) * * *
TTI XYZ COMPANY
FILE MODE OPTION ADDRESS (GROUP) RESULT PAGE
* * * JOURNAL(NOV.24.1998 11:07PM) * * *
TTI XYZ COMPANY
<RX>
DATE TIME ADDRESS MODE TIME PAGE RESULT PERS.NAME FILE
<TX>
DATE TIME ADDRESS MODE TIME PAGE RESULT PERS.NAME FILE
GFLIST0N
