Machine Settings
Printing the Remaining Amount of a Media
The present remaining amount of a media can be printed.
1
In LOCAL, Press .
• LOCAL changes to the origin setting mode.
2
Press to set a light point of the LED pointer to the changing
position.
• Move the carriage and media with and set
the origin.
• When you do not change the origin, do not press
and proceed to Step 3.
• When you press the key here, the origin is changed,
and the screen returns to LOCAL.
3
Press the key.
• When you press , the screen returns to
Step 2.
• When you press the key, the screen returns to LOCAL.
4
Press the key.
• The remaining amount of a media starts to be printed.
• When the printing has been completed, the screen returns to LOCAL.
• Set "Remaining amount of a media to display" to "ON".
• When you replace the media you use now with another, it is recommended that you print the
remaining amount of the media on it.With the remaining amount of a media having been printed
beforehand, when you use the replaced media again, you can enter an accurate value in the screen
for entering the remaining amount of a media ( P.2-12) that appears after media detection.
• When the remaining amount of a media has been printed with the origin changed, the origin set here
is effective even when subsequent data are printed.
OR I G I N SETUP
0.0 0.0
Origin
(Length)
Origin
(Width)
