Netcam(W)_SNC-L200(W)
53
Setting the Smart Viewer
You can set a variety of menus such as system, network,
administrator settings and firmware upgrade over the Netcam(W)
Website.
Netcam(W)_SNC-L200(W)
52
Using the Simple Player
Simple Player Screen
1. Open Button: Open files to be played back.
2. Playback Button: Play back files.
Reverse Playback Button: Reverse playback files.
Pause Button: Stop playback for seconds.
Stop Button:
Stop playback. (the screen appears at the beginning of the playback file)
Previous Image Button: View the previous images cut by cut in Pause mode.
Next Image Button: View the following images cut by cut in Pause mode.
Previous File Button: Move to the previous file.
Next File Button: Move to the next file.
3. Playback Speed Button: Set the playback speed faster or slower.
(X0.1,X0.2,X0.5,X1,X2,X4,X8,X10)
4. Enlarge Button:Enlarge images.
Contract Button: Contract images.
Original Size Button: View images in original size.
5. Snapshot Button: Capture playback images in JPEG files.
6. Print Button: Print images.
7. Scroll Bar: Move the playback position by moving the scroll bar with a mouse.
You can move to the image you want in Stop or Pause mode.
1
7
Menu Bar
2 3 4 5 6
Click the Smart Setting Tab in the Smart Viewer Screen.
- The Smart Setting screen appears.
Main Menu
- Click the Main Menu to view the Sub Menu on the left.
Sub Menu
- Click the Sub Menu to
set the sub menu.
Click
