7-6
CHAPTER7
20-BIN STAPLE SORTER (AR-SS2)
Staple sort
The STAPLE SORT mode staples copies of 8-1/2" x 11", 8-1/2" x
11"R, 8-1/2" x 14", and 11" x 17" sizes. For other paper sizes, use the
manual stapling mode. See page 7-8.
Using the document glass
1
Set the original on the document glass with the corner
to be stapled to the upper right.
●
Copy from the last page to the first page.
●
If the number of copies to be delivered into each bin is more than
30 for 8-1/2" x 11" or 8-1/2" x 11"R paper or 25 for 8-1/2" x 14"
or 11" x 17" paper, the copies will not be stapled.
2
Press the OUTPUT key and select the STAPLE SORT
mode.
●
Make sure that there is no paper in any sort bin before selecting
the STAPLE SORT mode.
3
Set the number of copies.
●
Up to 20 sets can be made.
4
Press the COLOR COPY START ( ) key or BLACK
COPY START ( ) key.
5
When all copies are made and sorted, press the manual
staple key.
●
Each set of copies will be stapled.
●
Sets of copies containing copies of different width will not be
stapled.
OPTIONAL EQUIPMENT
20-bin staple sorter (AR-SS2)
Stapling position
SORT
STAPLE
SORT
GROUP
OK
PAPER SELECT
100%
COPY RATIO
8/ 11AUTO
1
2
C
CA
CLEAR
INTERRUPT
CLEAR
ALL
12
3
456
789
0
P
C
CL
PROGRAM
AUDIT
INTE
CLE
AL
