Main Logic Board
DRWG.NO. REV. PARTS NO. PARTS NAME Q’TY REMARKS RANK
C36-41 NOT MOUNTED
CRA1-3 06542211 RESIS. ARRAY CHIP V8V221J 3
CRA4-8 06544711 RESIS. ARRAY CHIP V8V471J 5
CRA9-10 06542211 RESIS. ARRAY CHIP V8V221J 2
D1-2 08000047 DIODE CHIP DCB010 2
D3 08000068 DIODE CHIP MC2836 1
D4-5 08000059 DIODE CHIP MC2840 2
D6 NOT MOUNTED
D7-9 08000091 DIODE DSM1SD2*A 3
DT1 07603017 DIGITAL TRANSISTOR FN1A4P 1
DT2-4 07603016 DIGITAL TRANSISTOR FA1A4P 3
DT5 07603017 DIGITAL TRANSISTOR FN1A4P 1
DT6 07603016 DIGITAL TRANSISTOR FA1A4P 1
DT7 07603017 DIGITAL TRANSISTOR FN1A4P 1
DT8-9 07603016 DIGITAL TRANSISTOR FA1A4P 2
DT10-11 07603017 DIGITAL TRANSISTOR FN1A4P 2
DT12 07603016 DIGITAL TRANSISTOR FA1A4P 1
DT13 07603017 DIGITAL TRANSISTOR FN1A4P 1 TSP242/242-24
DT14 07603017 DIGITAL TRANSISTOR FN1A4P 1
DT15 07603016 DIGITAL TRANSISTOR FA1A4P 1
DT16 07603017 DIGITAL TRANSISTOR FN1A4P 1
L1-6 09990730 BEADS INDUCTOR BK2125HS601 6
L7 09990725 BEADS INDUCTOR RIB-6-6-C-C8 1
L8-10 09990730 BEADS INDUCTOR BK2125HS601 3
L11-17 06750004 CHIP RESISTOR 0 OHM 1/10W 7
L18-20 09990730 BEADS INDUCTOR BK2125HS601 3
VR1 06451035 RP RESISTOR RH0614C-10K 1
RA1 06584729 RESIS. ARRAY 4.7K-OHM 1/8W 8EL 1
RA2 06581824 RESIS. ARRAY 1.8K-OHM 1/8W 6EL 1
R1-3 06754711 CHIP RESISTOR 470 OHM 1/10W 3
R4-7 06753324 CHIP RESISTOR 3.3 K-OHM 1/10W 4
R8-9 06751031 CHIP RESISTOR 10 K-OHM 1/10W 2
R10-14 06754711 CHIP RESISTOR 470 OHM 1/10W 5
R15-17 06751031 CHIP RESISTOR 10 K-OHM 1/10W 3
R18 06754711 CHIP RESISTOR 470 OHM 1/10W 1
R19-20 06752215 CHIP RESISTOR 220 OHM 1/10W 2
R21 06754711 CHIP RESISTOR 470 OHM 1/10W 1
R22-23 NOT MOUNTED
R24 06751031 CHIP RESISTOR 10 K-OHM 1/10W 1
R25 06754721 CHIP RESISTOR 4.7 K-OHM 1/10W 1
R26 06751031 CHIP RESISTOR 10 K-OHM 1/10W 1
R27 06754721 CHIP RESISTOR 4.7 K-OHM 1/10W 1
R28 06752215 CHIP RESISTOR 220 OHM 1/10W 1
R29 06754721 CHIP RESISTOR 4.7 K-OHM 1/10W 1
R30 06751031 CHIP RESISTOR 10 K-OHM 1/10W 1
R31 06754721 CHIP RESISTOR 4.7 K-OHM 1/10W 1
R32 06751824 CHIP RESISTOR 1.8 K-OHM 1/10W 1
R33 06753334 CHIP RESISTOR 33 K-OHM 1/10W 1
R34 06751031 CHIP RESISTOR 10 K-OHM 1/10W 1
R35-39 06754721 CHIP RESISTOR 4.7 K-OHM 1/10W 5
R40 06751525 CHIP RESISTOR 1.5 K-OHM 1/10W 1
R41 06751021 CHIP RESISTOR 1 K-OHM 1/10W 1
R42 06751031 CHIP RESISTOR 10 K-OHM 1/10W 1
R43 *1 06753314 CHIP RESISTOR 330 OHM 1/10W 1
#1 06751014 CHIP RESISTOR 100 OHM 1/10W 1
R44 06751021 CHIP RESISTOR 1 K-OHM 1/10W 1
