Chapter 2 StorEdge A3500 Configurations 2-5
2.1.2 1x5 Configuration
2.1.2.1 Option Switch
All StorEdge D1000 disk arrays in this configuration should have their option
switches set as shown in
FIGURE 2-5.
FIGURE 2-5 1x5 Option Switch Settings for StorEdge D1000 Disk Array
This will cause the disk drives in the StorEdge D1000 disk arrays to be numbered as
shown in
FIGURE 2-6 and FIGURE 2-7.
FIGURE 2-6 8-drive StorEdge D1000 SCSI ID (Single Bus)
FIGURE 2-7 12-drive StorEdge D1000 SCSI ID (Single Bus)
53124
123 8910110
123 8910110121345
