ADJUSTMENT
3-8. Clock frequency adjustment and phase adjustment
Supply fine pitch signal (such as Windows shut-down screen) and adjust CLOCK and PHASE
to eliminate moiré and jitter.
3-9. Image position adjustment
Initially image position should be adjusted using the mechanical adjustments so that all
unmagnified images appear at the same position. Use POSI to electronically shift the image
and CAP to select the position of the image for magnification.
3-10. Screen Mode Selection
Incoming signals are automatically synchronized and the relevant timing data is stored in
memory so that this data can be read out each time a particular source is recognized. RGB1 and
RGB2 settings are memorized separately. There are a total of 10 memory areas available, if
additional frequencies are supplied the earlier settings will be lost.
Auto-adjustment can be switched on or off by pressing SPECIAL and then 1
3-11. On-Screen-Display, OSD
The default condition is for the OSD to be on, this can be switched off by pressing the CALL
button in Adjust Mode.
It is possible to change the color of the OSD:
SPECIAL A = red, SPECIAL B = green, SPECIAL C = blue, SPECIAL 8 = white.
3-12. Video Enhancer
When video input is selected the following adjustments are available: COLOUR , TINT
(NTSC only) and SHARP
3-13. Interpolation Filter
Filtering can be switched on and off by pressing SERVICE and then 4
3-14. Image direction
The image orientation can be flipped up, down, left and right using the FLIP key.
3-15. Status Indication
Pressing CALL in Normal Mode will display general information such input selection and
source frequency.
Pressing SPECIAL and then D in Adjust Mode will display software version and date.
SPECIAL F will display the lamp timer and SPECIAL E will display lamp history.
3-16. Power ON delay
This can be set in intervals of 0.5secs by pressing SPECIAL 9
