Trion’s Air Boss media units are industrial air cleaners

designed for both general ventilation (removal of

airborne pollutants from plant atmospheres) or source

capture (ductwork or arms positioned at the origin of

pollutants). These units help solve welding smoke,

oil mist, rubber dust, diesel smoke, grinding dust,

numerous gases/odors and many other indoor air

pollution problems.

Features & Beneﬁts

Straight Through or Side Discharge — Ability •

toBetterControlAirow(M3000&M6000)

OdorandHighEfciencyFilters—FromHEPA•

andAdsorberModulestoMini-PleatFilters

(194/388Sq.Ft.)forMaximumEfciency

andEffectiveness(M3000&M6000)

BeltDrivenBlowerwithVariablePitchSheave•

—ProvidingAdjustmentforPreciseCFM

OperatingRange(M3000&M6000)

CollectsWetorDryParticulates—•

ProvidingVersatilityinaWideRange

ofApplications(M3000&M6000)

HighStaticBlowerPackages—Capacity•

forAdditionalExternalStaticOffersMore

ContaminantPickupPoints(OptionalForM3000)

How it Works

Trion’sAir Boss Media Series uses the Interception

FiltrationPrinciple.Dirty,pollutedairisdrawnthrough

the pre-lter to remove larger dust particles. The

second stage, micro-glass deep pocket media lter

removes submicron particles from the air stream by

interception. The small diameter bers in the lter

intercept and retain these small particles while the

largesurfaceareaoftheltergiveslonglifeandlow

pressure drop. The blower is designed specically

tohandletheltrationsystematratedCFMoverthe

usefullifeofthelter.

Dirty Air

Clean Air

Media Air Cleaning Process

Pre-Filter MainFilter
