Cooling method Built-in cooling fan
Battery Access Battery access door allows hot-swap battery replacement without powering connected equipment off
ENVIRONMENTAL
Relative Humidity 0 to 95%, non-condensing
Storage Temperature +5 to +122 degrees Fahrenheit
Operating
Temperature
+32 to +104 degrees Fahrenheit
Line mode BTU/hr.
(Max.)
669.8 BTU / hr. (at full load)
Battery mode
BTU/hr. (Max.)
1417 BTU / hr. (at full load)
COMMUNICATIONS
Network monitoring
port
Includes built-in USB and DB9 serial ports. Each supports on battery, low battery, power restored, AC line voltage, DC
battery voltage, load percentage, battery charge current, battery capacity, internal UPS temperature and line frequency
status messaging
Software and
cabling included
Includes PowerAlert UPS monitoring software for all common network and stand-alone operating systems. Ships with
USB and DB9 serial cables
SNMP compatibility Built-in accessory slot accommodates internal SNMP/Web card and other network accessories
WatchDog
compatibility
Compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment via soft reboot of
applications/OS or hard power off/on reboot of connected equipment; ideal for unattended kiosk applications
LINE / BATTERY TRANSFER
Transfer time from
line power to battery
mode
2-4 milliseconds
Low voltage transfer
to battery power
167VAC (resets to line power as voltage increases to 176VAC)
High voltage
transfer to battery
power
260V (resets to line power as voltage decreases to 254VAC)
SPECIAL FEATURES
EPO port Includes RJ11 EPO (emergency power off) port and interconnection cable
TVSS grounding Includes back panel grounding point with thubscrew for data line surge suppressors and other network accessories
requiring a safe grounding point
Cold Start Inverter can be cold-started to provide temporary AC output during a power failure
Appearance Attractive all-black housing
BATTERY PACK ACCESSORY (optional)
Battery Pack
Accessory (optional)
BP48V60RT3U
CERTIFICATIONS
Certifications Tested to UL1778 (USA), CSA C22.2 No. 107.3 (Canada), NOM (Mexico), Class A (emissions)
WARRANTY
Product Warranty
Period
2 year product warranty
Connected
Equipment Coverage
$250,000 connected equipment insurance (USA / Canada only)
Optional Coverage 3 year, 5 year, next day and on-site warranty coverage available for select opportunities
