21

RF Unit

Parts List

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

PCB with Component (w/o Q1039) CB1946001

Printed Circuit Board FR008050B 1-

C 1001 CHIP CAP. 0.001uF 630V R GHM1030R102K630PT K22281801 1- A G1

C 1002 CHIP CAP. 220pF 50V CH GRM39CH221J50PT K22174243 1 B f2

C 1002 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 2- B f2

C 1003 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A B2

C 1004 FILM CAP. 15pF 500V UC232H0150J-T K33279028 1- A G1

C 1005 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B g3

C 1006 CHIP CAP. 39pF 50V CH GRM39CH390J50PT K22174225 1- A G2

C 1007 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A C3

C 1008 CHIP CAP. 8pF 200V CH GRM40CH080D200PT K22230214 1- A G1

C 1009 FILM CAP. 39pF 500V UC232H0390J-T K33279038 1- A G2

C 1010 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1 B e2

C 1010 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 2- B e2

C 1011 FILM CAP. 39pF 500V UC232H0390J-T K33279038 1- A G2

C 1012 AL.ELECTRO.CAP. 1000uF 25V RE2-25V102M 1000UF K40149034 1- A B2

C 1013 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B g6

C 1014 FILM CAP. 6pF 500V UC232H0060D-T K33279045 1- A G2

C 1015 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B f2

C 1017 CHIP CAP. 0.0022uF 50V B GRM39B222K50PT K22174822 1- B d2

C 1018 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- B d2

C 1020 CHIP CAP. 0.0022uF 50V B GRM39B222K50PT K22174822 1- B d2

C 1021 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B g4

C 1022 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B c3

C 1023 AL.ELECTRO.CAP. 10uF 16V RV2-16V100MB55-R K48120014 1- A B3

C 1024 CHIP CAP. 2pF 50V CK GRM39CK020C50PT K22174203 1- A G4

C 1025 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B c6

C 1026 CHIP CAP. 15pF 50V CH GRM39CH150J50PT K22174215 1- A H3

C 1027 CHIP CAP. 15pF 50V CH GRM39CH150J50PT K22174215 1- A G3

C 1028 CHIP CAP. 18pF 50V CH GRM39CH180J50PT K22174217 1- A G3

C 1029 CHIP CAP. 10pF 50V CH GRM39CH100D50PT K22174211 1- A H3

C 1030 CHIP CAP. 18pF 50V CH GRM39CH180J50PT K22174217 1- A G3

C 1031 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B b3

C 1032 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- B b2

C 1033 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E3

C 1034 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A F2

C 1035 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B c2

C 1036 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B c2

C 1037 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E3

C 1038 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B c2

C 1039 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B c2

C 1040 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B d4

C 1041 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- B d4

C 1042 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- B e4

C 1043 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A E3

C 1044 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B d4

C 1045 CHIP CAP. 6pF 50V CH GRM39CH060D50PT K22174207 1- B d4

C 1046 CHIP CAP. 15pF 50V CH GRM39CH150J50PT K22174215 1- A G3

C 1047 CHIP CAP. 33pF 50V CH GRM39CH330J50PT K22174223 1- A G3

C 1048 CHIP CAP. 18pF 50V CH GRM39CH180J50PT K22174217 1- A G3

C 1050 CHIP CAP. 15pF 50V CH GRM39CH150J50PT K22174215 1- A G3

C 1051 CHIP CAP. 220pF 50V CH GRM39CH221J50PT K22174243 1- A F4

C 1052 CHIP CAP. 39pF 50V CH GRM39CH390J50PT K22174225 1- A G3

C 1053 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B e5

C 1054 CHIP CAP. 6pF 50V CH GRM39CH060D50PT K22174207 1- A G4

C 1055 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B b4

C 1056 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- B b2

C 1057 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A D3

C 1058 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- B c2

C 1059 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- B c2

C 1061 CHIP CAP. 0.027uF 25V B GRM39B273K25PT K22144810 1- A E2

C 1062 CHIP TA.CAP. 10uF 25V TEMSVC1E106M12R K78140021 1- A E2

C 1063 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A D6

C 1064 CHIP CAP. 18pF 50V CH GRM39CH180J50PT K22174217 1- A D5

C 1066 CHIP CAP. 22pF 50V CH GRM39CH220J50PT K22174219 1- A E5

C 1067 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A G3

C 1068 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B e6

C 1069 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B e6

C 1070 CHIP CAP. 220pF 50V CH GRM39CH221J50PT K22174243 1- A C6

C 1071 CHIP CAP. 12pF 50V CH GRM39CH120J50PT K22174213 1- A G3

C 1072 CHIP CAP. 2pF 50V CK GRM39CK020C50PT K22174203 1- B c5

C 1073 CHIP CAP. 22pF 50V CH GRM39CH220J50PT K22174219 1- A G3

C 1074 CHIP CAP. 3pF 50V CJ GRM39CJ030C50PT K22174204 1- B c5

C 1075 CHIP CAP. 33pF 50V CH GRM39CH330J50PT K22174223 1- A G3

C 1077 CHIP CAP. 6pF 50V CH GRM39CH060D50PT K22174207 1- A G4

C 1078 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A E2
