— 12 —
Thermostat
Red Button
Baffle Knobs
PL-52624
OPERATION
WARNING: THE OVEN AND ITS PARTS ARE HOT. USE CARE WHEN OPERATING AND
CLEANING THE OVEN.
CONTROLS (Fig. 7)
Thermostat — Regulates gas flow to the burners to maintain set temperature. Temperature range
for the standard oven is 300-650°F; temperature range for the optional 115 Volt
control is 300-700°F.
Baffles — Adjustable baffles allow a positive balance of top and bottom heat. To increase top
heat and reduce bottom heat, pull the baffle knobs out. To reduce top heat and
increase bottom heat, push the baffle knobs in.
BEFORE FIRST USE
Clean the protective metal oils from all surfaces of the oven. Use a non-corrosive, grease dissolving
commercial cleaner, following manufacturer's directions. Rinse thoroughly and wipe dry with a soft
clean cloth. Clean all accessories. Rinse thoroughly and wipe dry.
Optional Pyrorock Core Plate "Break-In Procedure"
If your oven is equipped with the optional Pyrorock core plate, it is critical that the following break-in
procedure be followed before beginning any cooking operations. Failure to follow this procedure will
void any warranty consideration. Also, once the core plates have been dried, any reintroduction of
water will require that the break-in procedure be repeated.
Turn the oven on and set the thermostat to 300°F. Allow the oven to operate at this temperature for
a minimum of 5 hours. This procedure will eliminate the possibility of warpage caused by water
absorption.
Fig. 7
