Make sure that you have completed the instructions from Step 1 “Setting Up
the Machine” on pages 4 - 11.
1
Turn off and unplug the machine from the
AC outlet and disconnect it from your
Macintosh
®
if you already connected an
interface cable.
2
Turn on your Macintosh
®
.
3
Insert the supplied CD-ROM into your
CD-ROM drive.
4
Double-click the Start Here OSX icon to
install the printer driver and Remote Setup
program. If the language screen appears,
select your language.
5
Click MFL-Pro Suite to install.
6
Follow the on-screen instructions, and
restart your Macintosh
®
.
7
After the DeviceSelector window appears,
connect the network interface cable to your
Macintosh
®
and then to the machine.
To connect the network interface cable to
the machine:
1. Lift the scanner cover to its open
position.
2. Connect the network cable into the LAN
socket, marked with a symbol. You
will find the LAN socket above and to the
left of the ink cartridge slots, as shown
below.
For Network Interface Cable Users
For Mac OS
®
X 10.2.4 or greater
(Example for the U.K.)
The DeviceSelector window will not appear if
you have also connected a USB interface
cable to the machine before restarting your
Macintosh
®
or if you are overwriting a
previously installed version of the Brother
Software. If you encounter this problem
continue with skipping steps 10 through 12
and then see the Software User's Guide
Chapter 8 for details on selecting what
machine the ControlCenter2.0 will connect
with.
Continued...
Installing the Driver & Software
Setting Up
the Machine
For
Network Users
Macintosh
®
Network
Mac OS
®
8.6 - 9.2
