Unpacking
When unpacking your Portable Threading Machine, check to make sure the following parts are included. If any
parts are missing or broken, please call HARBOR FREIGHT TOOLS at 1-800-444-3353.
REV 09/02; 12/05
Maintenance
Step 1) Clean the Portable Threading machine after each use. Clean dies after each use. Check for
broken teeth or pipe material between teeth.
Motor Brushes
Step 1) Using a small standard screwdriver, remove the Brush Cap. When you remove the Brush Cap, the
Brush may spring out. Do not lose the Brush. If the brush does not spring out, gently remove it
using the tip of your screwdriver.
Step 2) Examine the Brush surface. If the Brush is worn more than 1/4" replace the brush. The surface
should be smooth and clean. If scratch marks appear, or if the brush is broken, replace the brush
immediately with an approved replacement brush from Harbor Freight Tools.
Step 3) Screw the Brush Cap back into the Brush Holder and tighten.
Store your Threading Machine in the Carrying Case provided. Make certain it is stored out of the reach of children.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS
MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES
ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED
TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY
PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES
THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LI-
CENSED TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
* Cutter Head includes cutter blades
traPnoitpircseDyt'QtraPnoitpircseDyt'QtraPnoitpircseDyt'Q
1rotoM17raeGmroW191recapS1
2revoCraeGmroW18gniRgniniateR102raeG1
3wercS49g
niR112recapS1
A4etalPeiD"2/1101recapS122recapS1
B4etalPeiD"4/3111gniR132wercSxeH21x5M2
C4etalPeiD"1121recapS142revoCeldnaH1
D4etalPeiD
"4/1-1131gniRpanS152recapS1
*A5daeHrettuC“2/1141gniraeB162wercS1
*B5daeHrettuC"4/3151tloB172gniR1
*C5daeHrettuC"116151x4yeKthgiartS18
2eldnaH1
*D5daeHrettuC"4/1-1171gniraeB192pmalC1
6gniR181gniraeB1
