PHONE OVERVIEW
PHONE OVERVIEW
13
1. Earpiece Lets you hear the caller.
2. Flip Open the case to answer an incoming call and close to end
the call.
3. LCD Screen Displays messages and indicator icons.
4. Left Soft Key Use to display the function setting menu.
5. SEND Key Use to place or answer calls.
6. Side Keys Use to adjust the ringer volume in standby mode and
the earpiece volume during a call.
7. BACK/Speakerphone Key Press to delete a single space or
character. Press and hold to delete entire words. Press this key
once in a menu to go back one level. In standby mode, press and
hold this key to turn speakerphone on.
8. Camera Key Use for quick access to Camera function.
9. Manner Mode Key Use to set Manner mode (from standby mode
press and hold for about 3 seconds).
10. Navigation Key Use for quick access to Contacts List, Ringers,
Axcess Apps and Axcess Web.
11. Right Soft Key Use to select an action within a menu.
12. Charger Port Connects the charger to the phone.
13. END/PWR Key Use to turn the power on/off and to end a call.
Also use to return to the main menu display screen.
14. Alphanumeric Keypad Use to enter numbers and characters and
select menu items.
15. Microphone Lets callers hear you.
16. Lock Mode Key Use in standby mode to set the lock function by
pressing and holding the key for about 3 seconds.
17. Camera Lens
Projects the object when taking a picture.
18. Earphone Jack Allow the use of a headset to hear caller's voice.
19. Outside Display Displays the outside LCD screen.
1
17
18
19
10
11
12
13
15
14
16
2
4
5
6
7
8
9
3
