106 Section 2I: Using the micro SD Card
microSD Icon Indicators
The following icons will appear on your phone’s display screen
when a microSD card is properly inserted into the microSD
card slot:
Indicates that a microSD memory card has been
inserted into your phone.
Note: DO NOT remove a microSD card while files are being accessed or
transferred. It will result in loss or damage of data. Make sure your battery is
fully charged before using the microSD card. Your data may become
damaged or unusable if the battery runs out while using the microSD card.
Using the microSD Adapter
The supplied microSD adapter allows microSD cards to be
used in SD compatible devices. Before using the
SD-compatible host, you will need to insert the microSD card
into the microSD adapter.
To insert the microSD card into the microSD adapter:
ᮣ
With the label side of the microSD card facing up, insert
the card into the supplied TransFLASH™ adapter and
gently slide the card until it is fully inserted.
To remove the microSD card from the microSD adapter:
ᮣ
Hold the front edge of the microSD card and gently pull
outward to remove it from the adapter.
microSD Card
Adapter
SD-compatible device
(USB Reader/Writer)
