The Battery
The phone comes with a
rechargeable battery. Keep the
battery charged while not in use
in order to maximize talk and
standby time. The battery charge
level is shown at the top of the
LCD screen.
Installing the Battery
Remove the battery cover by
sliding it downward followed by
the arrow indicator. Align the
battery with the terminals near
the top of the phone. Align the
battery cover then slide it to the
right side until it clicks into
place.
Removing the Battery
Turn the phone off. Slide the
battery cover to left side and
remove it. Use the opening near
the top of the battery to lift the
battery out.
Charging the Battery
To use the charger provided with
your phone:
Warning! Use only the charger
provided with the phone. Using
any charger other than the one
included with the AX300 may
damage your phone or battery.
Note
It is important to fully charge the
battery before initial use of the
phone.
Getting Started with Your Phone
18
Getting Started with Your Phone
AX300_Eng_0403.qxd 2008.4.18 2:15 PM Page 18
