Getting Started
17
4. To insert the battery, align the
golden contacts of the battery with
the corresponding connectors on
the battery compartment. Press
down on the opposite end of the
battery until it snaps into place.
5. Attach the back cover by sliding up
into position until it clicks.
Charging the Battery
The use of unauthorized accessories
could damage your phone and void
your warranty.
To use the travel charger provided
with your phone:
1. With the battery in position on the
phone, connect the lead from the
travel charger to right side of the
phone. Check that the arrow on the
lead connector is facing towards
the front of the phone.
2. Connect the travel charger to a
standard AC wall outlet. Only use
the travel charger that was
provided with the phone.
▲
▲
Note
When you need to remove the SIM,
slide it, as shown, and take it out of
the socket.
