NTI RACKMUX RACKMOUNT ANSI TERMINAL DRAWER
13
-----------------------------------------------------------------------------------------------------------------------------------------------------
F11- Colr2 Set-up Menu
-----------------------------------------------------------------------------------------------------------------------------------------------------
The color functionality differs with emulation. In general VT100, VT220 and ANSI Console work with applications, which control
the color directly. The remaining personalities associate colors based on existing monochrome video attributes. This section will
define parameter selection based on personality selected.
Background = Will determine the color of the background screen under some conditions (16 colors).
Normal F.G. \ Normal B.G. = These fields allow the user to select the character and background color (16 colors) for data
entered on the display before the application defines the color display remotely.
Border Color = The color of the border around the edge of the screen.
Cursor = Will select the color of the cursor (16 colors).
Intensity F.G. \ Intensity B.G. = These fields allow the user to select the character and background color (16 colors) for
data entered on the display as Dim in ASCII emulation's and Bold in VT\ANSI emulation's before the application defines the color
display remotely.
Attribute = Bold/Blink
Color mode = Is automatically selected based on the emulation selected.
Color map = Applies in WY325 mode only and determines if the monochrome attribute Reverse or Blank will be used to map
monochrome attributes to color.
Color Association = OFF/ON
Table 3- Color Setup Menu
Option ASCII (NOT WY325) WY325 * VTXXX ANSI CONSOLE
Background =
The whole data area of the
screen will be displayed in this
color, when the application
hasn't entered character or
spaces with the Normal or
Intensity B.G. color. Changes
in Background color will
affect Normal and Intensity
B.G. Any clear screen
commands will clear to this
color.
No Function Same as ASCII Same as ASCII
Cursor =
Selects Cursor color Selects Cursor color Selects Cursor color Selects Cursor color
Normal F.G. =
Selects color of Normal F.G. No Function Initial color selection
at power up
Initial color selection
at power up
Normal B.G. =
Selects color of Normal B.G. No Function Initial color selection
at power up
Initial color selection
at power up
Intensity F.G. =
Selects color of Intensity F.G. No Function
Initial color selection
at power up
Initial color selection
at power up
Intensity B.G. =
Selects color of Intensity B.G. No Function Initial color selection
at power up
Initial color selection
at power up
Color Mode =
Normal/Palette
Automatic Automatic Automatic Automatic
Color Map =
No Function See Above No Function No Function
* When the WY 325 personality is selected holding the Ctrl key down and depressing either the 0, 1, ..., 9 or (.) period keys in
the numeric pad change the assignment of color on the screen. Each selection is called a palette and is described in Table 4.
