NTI RACKMUX RACKMOUNT ANSI TERMINAL DRAWER
28
Variable Values for Table 10 Commands (Cont'd)
p1
Function Key
p1
Function Key
1 F1 6 F6
2 F2 7 F7
3 F3 8 F8
4 F4 9 F8
5 F5 0 F10
P2
Function Key
1 Remote
2 Local
3 Normal
Page
Page
0 page 0 In the 80 columns mode: There have 4 pages of display memory.
1 page 1 In the 132 columns mode: There have 3 pages of display memory.
2 page 2 In the Econ-80 columns mode: There have 7 pages of display memory.
3 page 3
4 page 4
5 page 5
6 page 6
Palette Color Pallette Palette Color Pallette Palette Color Pallette
0 Palette 0 4 Palette 4 8 Palette 8
1 Palette 1 5 Palette 5 9 Palette 9
2 Palette 2 6 Palette 6 . Palette 10
3 Palette 3 7 Palette 7
Parity
Parity Bits
Parity
Parity Bits
0 None 2 Mark
1 Odd 3 Even
pp 2-byte hex value of character position
*f
.
*f In the illustrations, DEC = decimal value; HEX = hexadecimal value. Read across, then down.
Scroll
Scrolling Type
Speed (lps)
@ Jump scroll
< Smooth scroll 1
= Smooth scroll 2
> Smooth scroll 4
? Smooth scroll 8
sequence Up to 64 bytes to be loaded in function key
Set
Predefined Character Set
@ Native Mode
A PC Multinational
B Standard ASCII
D PC Standard
G Standard ANSI
Stop
stopbits
0 1
1 2
text 78 characters (80 columns); 130 characters (132 columns)
Volume
BELL Volume
Volume
BELL Volume
# Loud ! Low
“ Medium SP Off
