Display 60 – Reset counters to zero
************** ##############
* FIELD TEST * #Use menu to #
* DISPLAY * #reset field #
* COUNTERS * #test display#
* RESET * # counters #
************** ##############
With this display all counters of the field test display can be reset (i.e. all
counters in 40 and 60 series).
On poweroff the values of the counter displays are stored onto the EEPROM, where they
will be read during power on. To initialize the counters to zero, select display 60.
These counters are automatically reset to zero when they exceed their maximum value.
Display 61 – Search and reselection counter display
++++++++++++++ ##############
+NOPSW :aaaa+ #PSWMesgCntr #
+SYNCR :bbbb+ #SyncMeasCntr#
+RESELEC:cccc+ #CellReselCtr#
+ + # #
++++++++++++++ ##############
aaaa counter for MDI_NO_PSW_FOUND message received from DSP in hexadecimal form.
bbbb counter for synchronization measurement attempts in decimal form. If counter
value is over 9999 then four x are shown.
cccc counter for cell reselections in hexadecimal form.
Display 61 (dualband) – Search and reselection counter display
++++++++++++++ ##############
+aaaaa bbbbb+ #NOPswGSM DCS#
+ccccc ddddd+ #Sync GSM DCS#
+eeeee fffff+ #reselG>G D>D#
+ggggg hhhhh+ #reselG>D D>G#
++++++++++++++ ##############
aaaaa GSM900 counter for MDI_NO_PSW_FOUND message received from DSP in decimal
form (max 99999).
bbbbb GSM1800 counter for MDI_NO_PSW_FOUND message received from DSP in decimal
form (max 99999).
ccccc GSM900 counter for synchronization measurement attempts in decimal form. If
counter value is over 99999 then five x are shown.
ddddd GSM1800 counter for synchronization measurement attempts in decimal form. If
counter value is over 99999 then five x are shown.
eeeee counter for GSM900 -> GSM900 cell reselections in decimal form (max
99999).
fffff counter for GSM1800 -> GSM1800 cell reselections in decimal form (max
99999).
ggggg counter for GSM900 -> GSM1800 cell reselections in decimal form (max
99999).
hhhhh counter for GSM1800 -> GSM900 cell reselections in decimal form (max
99999).
