Installing the Coin-Cell Battery
1. Connect the coin-cell battery cable to the system board.
2. Attach the coin-cell battery to the adhesive on the system board.
3. Install the:
a. base cover
b. battery
4. Follow the procedures in After Working Inside Your Computer.
Removing the Audio-Connector Board
1. Follow the procedures in Before Working On Your Computer.
2. Remove the:
a. battery
b. base cover
3. Perform the following steps to remove the audio-connector board from the computer:
a. Disconnect the audio-connector board cable from the system board.
b. Remove the screw that secures the audio-connector board to the computer.
c. Lift and remove the audio-connector board from the computer.
