Option Description
• Fn Key Only (Default Setting)
• By Numlock
Numlock Enable Allows you to enable the Numlock when system boots. The option is
enabled by default.
Fn Key Emulation Allows you to match the <Scroll Lock> key feature of PS-2 keyboard with
the <Fn> key feature in an internal keyboard. The option is enabled by
default.
• Enable Fn Key Emulation
Fn Lock Options This option when enabled allows the hot key combination <Fn> +<Esc>
toggle the primary behavior of <F1> – <F12> between their standard and
secondary functions.
• Fn Lock Hot Key (Default Setting)
– Standard (Default Setting)
– Secondary
Fastboot Allows you to speed up the boot processes. The options are:
• Minimal (Default Setting)
• Thorough
• Auto
Extend BIOS POST Time This option creates an extra pre-boot delay. This allows you to see the
POST status messages.
• 0 seconds (Default Setting)
• 5 seconds
• 10 seconds
Table 10. Virtualization Support
Option Description
Virtualization This option specifies whether a Virtual Machine Monitor (VMM) can utilize
the additional hardware capabilities provided by Intel Virtualization
technology.
• Enable Intel Virtualization Technology (Default Setting)
Table 11. Wireless
Option Description
Wireless Switch Allows you to determine which wireless device can be controlled by the
wireless switch. The options are:
• WWAN
• Bluetooth
• WLAN
All options are enabled by default.
