WPAN/UWB Cards
Dell™Latitude™E6500ServiceManual
Removing a WPAN/UWB Card
Replacing a WPAN/UWB Card
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best practices information, see the
Regulatory Compliance Homepage at: www.dell.com/regulatory_compliance.
Your computer supports a Wireless Personal Area Network or a Ultra-Wide Band (WPAN/UWB) card. If you ordered a WPAN/UWB card with your computer, the
card is already installed.
Removing a WPAN/UWB Card
1. Follow the procedures in Before Working on Your Computer.
2. Close the display and turn the computer over.
3. Remove the left hinge cover (see Removing the Hinge Covers).
4. Remove the bottom of the base assembly (see Removing the Bottom of the Base Assembly).
5. Disconnect the blue antenna cable from the WPAN/UWB card.
6. Remove the M2x3 screw from the WPAN/UWB card.
7. Slide the WPAN/UWB card at a 45-degree angle out of its connector.
