EPL-N2700 Revision A
Product Description Panel Operation 44
LC1 - LC3 Counter Clear
A servicer performs this operation once whenever the feed roller
in the LC1/LC2/LC3 has been replaced.
This function returns the value for the LC1/LC2/LC3 Counter to
zero and the counter value for the LC1/LC2/LC3 FR Change
increases by one which are shown on the engine status sheet.
TR Counter Clear
A servicer performs this operation once whenever the transfer
roller has been replaced.
This function returns the value for the TR Counter to zero and
the counter value for the TR Change increases by one which are
shown on the engine status sheet.
Error Log Clear
Clears the error log list stored to print on the Engine Status Sheet.
The error log list stores the most recent 20 errors.
1.4.5.1 Engine Status Sheet
A sample print of the Engine Status Sheet is shown below:
Figure 1-6. Sample Engine Status Sheet
NOTE:
The Engine Status Sheet does not show the version number
of the options which are not installed.
NOTE:
Removal of options does not clear their counter values.
Engine Status Sheet
Total Counts
Jam Counts
ET Cartridge
Toner
OPC Counter
Cartridge Change
Fuser
Fuser Counter
Fuser Change
Input
LC1 Counter
LC2 Counter
LC3 Counter
MP Counter
LC1 FR Change
LC2 FR Change
LC3 FR Change
MP FR Change
Transfer Roller
TR Counter
TR Change
Adjust
MP
LC1
LC2
LC3
Duplex
Engine Version
MCU
Multibin
Finisher
Error Log
Panel Message
Code
Page
zzzzzzzzzzzzzzzzzzzz
xxxx
yyyyyyyy
600,000 sheets
100,000
100%
600,000 sheets
10
10
0.0 mm
-0.4 mm
020101
001012
000000
600,000 sheets
600,000 sheets
600,000 min
600,000 sheets
600,000 sheets
600,000 sheets
0.0 mm
0.0 mm
0.0 mm
10
10
10
10
10
