11. Have you checked for leaks at all water supply connections?
Operating Method
1. Turn on the water tap, letting the water enter the water tank, then turn the power
switch ON. The power switch’s indicator lamp lights, as well as the other three
indicator lights on the control panel.
2. After about 3 minutes, the ice maker will automatically proceed to the ice-making
stage, and the sound of flowing water will be heard. Only the red power switch lamp
and the green Ice Making LED will be on.
3. When the batch of ice has been fully formed, ice will automatically fall into the ice
storage bin. The yellow Ice Harvest LED will be on, and the other two will be off.
4. When the ice storage bin is full, the sheet of cubes will not fall completely and will
hold the ice-full probe open. The machine is in the ice-full mode, and the red Ice Full
LED will be lit. The other two LEDs will be off.
5. The unit starts making ice again after the ice cubes are removed. At the same time,
the ice-full probe swings back to operating position.
Ice-making stage Ice harvest stage
IMPORTANT:
• Although the unit has been tested and cleaned at the factory, due to long-term transit
and storage, the first batch of cubes must be discarded.
• Never turn the water supply tap off when the ice maker is working.
• Never touch the evaporator when the machine is running.
• Except to take ice from the unit, keep the door closed to reduce melting and insure
proper ice formation.
How the Machine Makes Ice
When the power switch is first turned ON, the machine is in Stand-by mode. After
about 3 minutes, it will automatically proceed to the ice-making stage.
There are two distinct cycles: Freeze and Harvest. During the Freeze cycle, water flows
to the evaporator surface. In the Harvest cycle, the ice is released and water enters the
machine. A complete cycle can take 15 to 40 minutes, depending on ambient
temperature and operating conditions.
Freeze: During the Freeze cycle the compressor is pumping refrigerant, the fan motor is
fully formed, the ice maker stops the Freeze cycle and begins the Harvest cycle.
Harvest: During the Harvest cycle the compressor is still operating, but the water pump
has stopped. The hot gas valve opens, diverting hot refrigerant gas into the
evaporator. The gas warms the evaporator, causing the cubes to slide as a unit off
the evaporator and into the storage bin. The Freeze cycle will restart when all the
cubes drop into the bin.
How the machine uses water:
