CONNECTING TO A GTX 330 MODE S TRANSPONDER
To receive Mode S TIS traffic data from a GTX 330 transponder on your GPSMAP
695/696, connect an available RS-232 OUT pin on the transponder to the Data In pin
on the GPSMAP 695/696. (You do not need to connect the transponder to the GPSMAP
695/696’s Data Out pin.) Then, set the corresponding RS-232 output configuration
on the transponder to REMOTE + TIS and set the GPSMAP 695/696’s Serial Data
Format to TIS In or TIS In/NMEA & VHF Out (refer to the Interfacing section). For more
information, see Appendix E and the GTX 330 Transponder Installation Manual.
INTERFACING
The following formats are supported for connection of external devices: NMEA 0180,
0182, 0183 (versions 1.5, 2.0, 2.3, 3.01), ASCII Text Output, and Garmin proprietary
formats for connecting to a Mode S transponder for TIS data, and to a Garmin aviation
NAV/COM radio.
The following are the Approved Sentences for NMEA 0183, version 3.01 output:
GPRMC, GPGGA, GPGSA, GPGSV, GPGLL, GPBOD, GPRTE, and GPWPL. The following
are the Proprietary Sentences for NMEA 0183, version 3.01 output: PGRME, PGRMZ,
PGRMM, and PGRMH.
The GPSMAP 695/696 also includes NMEA input with support for the BWC, DBT,
DPT, MTW, VHW, VTG, and XTE sentences.
Garmin’s proprietary communication protocol is available from the Web site (www.
garmin.com).
GENERAL INTERFACE SETUP
The Interface Setup controls the input/output format used when connecting the unit
to external devices.
Selecting an interface:
1)
Press the MENU Key twice to select the Main Menu.
2)
Turn or move the FMS Joystick to select ‘System Setup’, and press the ENT
Key.
3)
Turn or move the FMS Joystick to select ‘Interface’, and press the ENT Key.
4)
With the Serial Data Format field highlighted, turn the FMS Joystick to
select the desired Serial Data Format.
