NO. DESCRIPTION PART NO. QTY ITEM NOTE
47 Ratchet HOC Moulding 480147 1
48 Throwplate - Main Body 480011 1
49 Screw - Taptite 09545 4
50 Bearing - Roller Housing
219102 2
51 Roller - Rear W/A 480210 1
52 Spring Tension - Rear Axle 480133 2
53 Washer 09262 3
54 Screw - Taptite 09365 22
55 Bolt - Coach 09666 2
56 Nut 09657 1
57 Washer 09658 1
58 Rope - Stop MU42189 1
59 Handle 486016 1
60 Washer - Spring 03469 2
61 Sprocket - 17 Teeth 219051 1
62 Frame - Rear Roller W/A 480201 1 Includes item 103
63 Key - woodruff 5321 1
64 Circlip 1428 1
65 Washer 480097 4
66 Cover - Transmission 480206 1
67 Chain 480209 1
68 Rod - Connecting 480045 1
69 Plate - Securing 219037 2
70 Filler - Throwplate 480017W 1
71 Pulley - Sprocket Fixed Speed 480208 1
72 Belt - V APTO 486035 1
73 Washer 02575 1
74 Circlip 03096 1
75 Pulley - Jockey 219156 1
76 Washer - Starlock 0201086 2
77 Bracket - Idler Assy 480115 1
78 Belt Guide 480116 1
79 Pulley - Drive APTO 486034 1
80 Spring - Torsion Idler 480066 1
81 Bush 4452 1
82 Washer - M12 H.D. 09280 1
83 Washer - Spring 09273 1
84 Bolt - UNF 09121 1
85 Distance Piece - Cutterbar 4014 1
86 Cutterbar - 19” 480149 1
87 Cover - Throwplate Drive 480012 1
88 Disc - Friction 480070W 1
89 Spacer 480072 1
90 Cap - Hub 219143 2
91 Nut - UNF Nyloc 4486 2
92 Wheel 5218 2
1.30
PARTS LIST
