8Ć56 Troubleshooting
C4699Ć90000
PrintĆQuality Troubleshooting
PrintĆQuality Plot
The printĆquality plot for the HP DesignJet 250C/350C is represented below. (Printing it '
page 8Ć46.) The plot for the HP DesignJet 230/330 is similar, but only the patterns relevant to
the black cartridge are printed. Use a 10X magnifier to help identify plotĆquality problems.
1. - Area Fill.
2. - Nozzle Checkout.
3. - Vertical Line Straightness (VLS)
4. - Pen-to-Pen Alignment (Secondary Colors)
5. - Pen-to-Pen Alignment (Primary Colors)
- Fast/Draft
- Normal/Final
- Best/Enhanced
