6Ć6 Removal and Replacement
C4699Ć90000
Removing the Cartridge Caps
and Wiper Blades
WARNING
You are likely to get ink on your hands
while performing the following
procedure.
1 Open the top cover of the plotter.
2 Move the cartridge carriage to the right,
out of the serviceĆstation area.
3 Peel the cartridge caps and/or the wiper
blades from the top of the service station,
and remove them from the plotter.
Reassembling: Ensure that the cartridge
caps are clean, the wipers straight, and
the openings clear.
