IU 645 / 9826 23 TowerFeed
TM
for the HP LaserJet 5000
APPENDIX E - PCL Paper Selection Commands
Frequently used PCL commands for Paper Selection:
Command Function # Refers to HP LaserJet 5000
optional HP paper trays*:
ESC & l # H Selects Paper
Source
optional Tray* without 1x250 sheets* 2x250 sheets*
0 print/eject page
2 Man. Feed - Paper
3 Man. Feed - Envelope
7Auto Select
4 Tray 1 Tray 1 Tray 1
1 Tray 2 Tray 2 Tray 2
5 NA Tray 3 Tray 3
8NANATray 4
20 (TF Tray 1) Tray 3 Tray 4 Tray 5
21 (TF Tray 2) Tray 4 Tray 5 Tray 6
22 (TF Tray 3) Tray 5 Tray 6 Tray 7
23 (TF Tray 4) Tray 6 Tray 7 Tray 8
24 (TF Tray 5) Tray 7 Tray 8 Tray 9
25 (TF Tray 6) Tray 8 Tray 9 Tray 10
26 (TF Tray 7) Tray 9 Tray 10 Tray 11
*optional HP paper trays: The optional HP 250-sheet tray(s) can be
used together with TowerFeed, but the optional HP 500-sheet tray
is not supported.
ESC & l # A Sets Paper Size 2 = Letter
3 = Legal
26 = A4
27 = A3
6 = Ledger (11x17 in)
for other sizes please refer to your printer manual
ESC & n # Wd
mediatype
Selects Media
Type
# mediatype Panel Display**
6 Plain PLAIN
11 Preprinted PREPRINTED
11 Letterhead LETTERHEAD
13 Transparency TRNSPRNCY
11 Prepunched PREPUNCHED
7 Labels LABELS
5Bond BOND
9 Recycled RECYCLED
6 Color COLOR
11 Card Stock CARDSTOCK
6 Rough ROUGH
**indication for reference purposes only
