132 MFP disassembly/assembly ENWW
External section
Replacing the ozone filter
CAUTION Be sure the power cord has
been unplugged from the
wall outlet.
When replacing the ozone
filter, insert it in the opening
in the MFP as far as it will
go.
Procedure
1 Loosen two screws to remove the ozone
filter cover.
2 Replace the ozone filter.
3 Reinstall the above parts following the
removal steps in reverse.
Screw
Ozone filter cover
Screw
Ozone filter
Ozone filter cover
