NOTE:
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid
configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales
representative for information on CTO product offerings and requirements.
NOTE:
This product offering does not support HP Factory Express Server Configuration Level 1.
NOTE:
HP does not allow factory integration of options into standard models listed above.
Configure-to-order servers must start with a CTO Chassis.
NOTE:
FIO indicates that this option is a Factory Installable Option.
Step 1: Base Server Blade Configuration
Models
HP Integrity BL860c Server Blade
NOTE:
Choose from base models above.
NOTE:
Adding Option code "#0D1" to the Server Blade PN will integrate the
configured blade into the enclosure (which must be on the same order)
Configurable Model ships with:
Four embedded Gigabit Ethernet NIC ports plus (1) additional 10/100 NIC
dedicated to Integrity iLO 2 Management
Integrated LSI 1068 hardware RAID controller
Two small form factor (SFF) SAS hot plug hard drive bays
HP Integrity Integrated Lights-Out 2 Advanced Pack
Step 2: Choose Required Options (one of the following from each list unless
otherwise noted):
Processors
Select a base model (either 2P or 1P models) which has the desired CPU
offering.
Memory
HP 2GB PC4200 DDR-SDRAM(2x1GB DIMMs)
AD343A
HP 4GB PC4200 DDR-SDRAM(2x2GB DIMMs)
AD344A
HP 8GB PC4200 DDR-SDRAM(2x4GB DIMMs)
AD345A
NOTE:
Memory Modules consist of pairs of DIMMs
NOTE:
DIMMs must be installed in pairs
RAID 1 Configuration
Upgrade Option
Factory configured hardware RAID 1
AD248A#106
NOTE:
Requires two (2) SAS Hard Drives identical in speed and capacity
NOTE:
Ordering AD242A#106 provides factory configuration of the embedded
LSI 1068 SAS controller to RAID1.
QuickSpecs
HP Integrity BL860c Server Blade
Configuration Information - Factory Integrated Models
DA - 12671 U.S. QuickSpecs — Version 18 — 2/18/2009
Page 22
