Category Description
Wireless Integrated wireless local area network (WLAN) options by way of wireless module
Customer-accessible
Two WLAN antennas
Support for the following WLAN formats:
● Atheros 9485GN 802.11b/g/n 1×1 WiFi Adapter and 3012 Bluetooth 4.0 Combo
Adapter (select models only)
●
Atheros HB125 802.11b/g/n 1×1 WiFi Adapter (select models only)
● Broadcom 4313GN 802.11b/g/n 1×1 WiFi and 20702 Bluetooth 4.0 Combo
Adapter
● Ralink RT5390R 802.11b/g/n 1×1 WiFi Adapter
External media card HP Multi-Format Digital Media Reader supports the following digital card formats:
●
MultiMediaCard (MMC)
●
Secure Digital (SD) Memory Card
●
Secure Digital High Capacity (SDHC) Memory Card
● Secure Digital Extended Capacity (SDXC) Memory Card
Internal card One half-size Mini Card slot for WLAN
Ports
●
Audio-in (digital microphone)
●
Audio-out (stereo headphone)
●
RJ-45 (Ethernet, includes link and activity lights)
●
USB 3.0 ports (two on left side)
● USB 2.0 port (right side)
● VGA (Dsub 15 pin) supporting:
◦
1920x1200 external resolution @ 60 Hz
◦
Hot plug/unplug with auto-detect for correct output to wide-aspect vs.
standard aspect video
●
High-Definition Multimedia Interface (HDMI) version 1.4 supporting up to
1920x1200 @ 60 Hz
●
AC Smart Pin adapter
Keyboard/pointing devices Full size island style textured keyboard with numeric keypad (Black)
TouchPad with 2 buttons
●
Multitouch gestures enabled
●
Taps enabled as default
Power requirements Battery:
●
6 cell, 2.22 Ah, 47 Wh battery
●
6 cell, 2.55 Ah, 55 Wh battery
●
Supports fast charge
