Repair Information 4-9
5016-001
OPC Drive Motor Removal
1. Remove the right side cover, refer to the Right Side Cover
Removal on page 4-4.
2. Remove the three (3) screws [A] from the OPC drive motor.
3. Disconnect the OPC drive motor cable [B].
4. Slide the mechanism to the left and out of the printer.
Cam Sensor Removal
1. Remove the right side cover, refer to the Right Side Cover
Removal on page 4-4.
2. Remove the motor mounting stay assembly, refer to the Motor
Mounting Stay C Assembly Removal on page 4-13.
3. Unclip the cam sensor connection.
4. Remove the cam sensor.
