Detailed settings when “Assign Mode” is set to
“7.1ch + ZONE3”
When “Assign Mode” is set to “7.1ch + ZONE3”, set the following
items.
n
Speakers for ZONE3
Select speaker terminals that output audio in ZONE3.
The channels of speaker terminals selected for ZONE3 cannot be
output in MAIN ZONE.
FRONT WIDE/
HEIGHT2
(Default):
Outputs audio in ZONE3 from FRONT WIDE/
HEIGHT2 speaker terminals.
HEIGHT1:
Outputs audio in ZONE3 from HEIGHT1
speaker terminals.
SURROUND BACK:
Outputs audio in ZONE3 from SURROUND
BACK speaker terminals.
n
Height Layout
Select the height channel used.
This can be selected when the “Speakers for ZONE3” setting is
“FRONT WIDE/HEIGHT2” or “SURROUND BACK”.
AUDIO OUT connectors
Select items
HEIGHT1
None No height channels are used.
Front Height
(Default)
Front Height
Top Front Top Front
Top Middle Top Middle
Top Rear Top Rear
Rear Height Rear Height
Front Dolby Front Dolby
Surround Dolby Surround Dolby
