Remote control unit
.
A
Display
A
LEARN indicator
This is lit when setting the learning function for the remote control unit.
(v p. 273)
B
Information display
0
This displays “AVR” when operating this unit.
0
This displays the input source name when operating an external
device.
0
This displays “TV” when operating TV.
C
l indicator
This is lit when signals are sent from the remote control unit.
B
AVR operation button
When preset codes are registered to the remote control unit, press this
button and then operate the menu on the unit.
C
SET button
This is used for various settings on the remote control unit.
(v p. 265, 273, 276, 277)
D
ZONE SELECT button
These switch the zone (MAIN ZONE, ZONE2, ZONE3) that is operated
through the remote control unit. (v p. 173, 178)
E
Device operation buttons (DEVICE X / DEVICE MENU)
These turn the power of external devices on/off and call up menus.
Preset codes need to be registered in order to use these buttons.
(v p. 266)
F
Input source select buttons
These select the input source. (v p. 79, 173)
