● Prompt password — If you must enter the
password every time you log in to a server, or if you
do not want to save your password in the device,
select Yes.
● Password — A password may be needed to make
a data connection and is usually provided by your
service provider.
● Authentication — Select Secure to always send
your password encrypted or Normal to send your
password encrypted when possible.
● Homepage — Depending on the access point you
are setting up, enter the web address or the address
of the multimedia message centre.
● Use access point — Select After confirmation if
you want the device to ask for confirmation before
the connection using this access point is created, or
Automatically if you want the device to connect to
the destination using this access point
automatically.
Select Options > Advanced settings and from the
following:
● Network type — Select the internet protocol type
to transfer data to and from your device. The other
settings depend on the selected network type.
● Phone IP address (for IPv4 only) — Enter the IP
address of your device.
● DNS addresses — Enter the IP addresses of the
primary and secondary DNS servers, if required by
your service provider. To obtain these addresses,
contact your internet service provider.
● Proxy server address — Enter the address of the
proxy server.
● Proxy port number — Enter the port number of
the proxy server.
WLAN internet access points
Select Menu > Settings and Connectivity >
Destinations > Access point, and follow the
instructions on the screen.
To edit a wireless LAN (WLAN) access point, open one
of the access point groups and select an access point
marked with
.
Follow the instructions from your WLAN service
provider.
● WLAN network name — Select Enter manually or
Search for networks. If you select an existing
network, WLAN network mode and WLAN security
mode are determined by the settings of its access
point device.
● Network status — Define whether the network
name is displayed.
● WLAN network mode — Select Ad-hoc to create
an ad hoc network and to allow devices to send and
receive data directly; a WLAN access point device is
not needed. In an ad hoc network, all devices must
use the same WLAN network name.
65
Connectivity
