Table 1.2: Connectors
Label Function
CN1 Primary IDE connector
CN2 Secondary IDE connector
CN3 Floppy drive connector
CN4 Parallel port
CN6 USB port
CN7 VGA connector
CN8 10/100Base-T Ethernet connector
CN9 Serial port: COM1
CN10 Serial port: COM2
CN11 PS/2 keyboard and mouse connector
CN12 External keyboard connector
CN13 Infrared (IR) connector
CN14 CPU fan connector
CN16 Power LED
CN17 External speaker
CN18 Reset connector
CN19 HDD LED connector
CN20 ATX feature connector
CN21 ATX soft power switch
CN27 Extension I/O board connector
CN28 Extension I/O board connector
CN29 External SM bus connector
CN30 External PCI extension connector
CN33 PS/2 mouse connector
CN34 10/100Base-T Ethernet connector 2
CN43 AC-97 audio extension interface
CN46 Auxiliary power input
ATX1 ATX12V auxiliary power input
