Troubleshooting
108
9
Removing Misfed Paper
When a paper misfeed occurs, an er-
ror message appears on the panel dis-
play. The procedure you should
follow to remove the misfed paper
depends on the location of the mis-
feed, which is indicated on the panel
display.
CAUTION:
Important
❒
More than one misfed areas might
be indicated. In this case, check ev-
ery applicable area. See the follow-
ing charts shown in the
illustration.
❒
If paper continues to misfeed,
check the following points.
• Confirm that the setting of the
paper size dial matches the size
and feed direction of the paper
loaded in the paper tray.
• Confirm that the toner bottle is
set correctly.
❒
If paper misfeed still occurs, con-
tact your sales or service represen-
tative.
❒
Do not leave any torn paper scraps
within the printer.
When "Misfeed:A" Appears
A
Open the bypass tray (
A
). And
then open the duplex unit by
pushing the catch upwards (
B
).
B
Open the right cover by pushing
the catch upwards.
•
When removing misfed paper,
do not touch the fusing section
because it becomes very hot.
Y
D
C
Z
A
B
U
W
R
R
TAPH200E
TAPH030E
ባ
ቢ
TAPH050E
